NFPA 72 (2022 Edition)
Section 10.6.7.2.1 requires 24 hours of standby followed by 5 minutes of alarm operation (15 minutes for voice evacuation systems). A 1.25 aging correction factor applies per Section 10.6.7.2.14.
BS 5839-1:2025
Requires 24 hours of standby followed by 30 minutes of alarm operation. Category P systems for unoccupied buildings require standby of 24 hours plus the unoccupied period, up to 72 hours maximum. Battery formula is in Annex E (normative).
Capacity = (Istandby × Tstandby + Ialarm × Talarm) × 1.25
Cmin = 1.25 × (I1 × T1 + D × I2 × T2)
Minimum Required Capacity
Installed Battery Is Adequate
The Ah battery meets the minimum requirement.
Installed Battery Is Inadequate
The Ah battery does not meet the Ah minimum. Consider upgrading to at least Ah.
Note: Select the next standard battery size above the calculated minimum. For 24V systems, use two 12V batteries of the same capacity in series. Always verify that the panel’s charging circuit supports the selected battery size.
How to Calculate Fire Alarm Battery Size
Every fire alarm system needs a secondary power source – typically sealed lead-acid (SLA) batteries – to keep the system operational during a mains failure. Getting the battery size right matters: undersized batteries can leave a building unprotected during a power outage, while oversized batteries may exceed the panel’s charging capability.
The fire alarm battery calculator above applies the battery sizing formulas from NFPA 72 (2022 edition) and BS 5839-1:2025, the two most widely used fire alarm standards globally. Both follow the same basic principle: calculate the energy needed for a defined standby period plus a worst-case alarm period, then apply correction factors to account for battery degradation over time.
NFPA 72 vs. BS 5839-1: Key Differences
While both standards require secondary power backup, the specifics differ significantly – particularly in alarm duration and how they handle high-rate discharge.
NFPA 72 (2022)
- Standby: 24 hours (4h with qualifying generator)
- Alarm: 5 minutes (standard) or 15 minutes (voice evacuation / MNS)
- Aging factor: 1.25 (25%)
- Derating: Not included in formula
- Recharge: Full recharge within 48 hours
- Battery replacement: Every 4 years from installation
BS 5839-1:2025
- Standby: 24 hours (6h with generator); up to 72h for Category P unstaffed
- Alarm: 30 minutes (all system types)
- Aging factor: 1.25 (25%)
- Derating: 1.75 (or 2.0 simplified)
- Recharge: Full recharge within 24 hours
- Battery replacement: Per manufacturer, minimum 4-year life
The BS 5839-1 formula typically produces larger battery requirements than NFPA 72 for equivalent systems. The 30-minute alarm duration is six times longer than NFPA’s standard 5 minutes, and the derating factor (D = 1.75) compensates for reduced battery performance at high discharge rates – something NFPA 72 does not explicitly address in its formula.
The Formulas Explained
Fire Alarm Battery Calculation Mistakes
- Unit confusion – mixing milliamps and amps is the most common error, producing results that are off by a factor of 1,000
- Using the old NFPA aging factor – the 2022 edition changed this from 1.20 to 1.25; many resources still reference the old value
- Forgetting loads – network cards, DACT communicators, annunciators, and relay modules all draw current and must be included
- Wrong strobe candela settings – a 15cd strobe draws far less current than a 110cd strobe; use the correct specification
- Not converting alarm time to hours – 5 minutes = 0.0833 hours, not 5
Standby Duration by System Type
| Standard | System Type / Category | Standby | Alarm Duration |
|---|---|---|---|
| NFPA 72 | Standard fire alarm (no generator) | 24 hours | 5 minutes |
| NFPA 72 | Standard fire alarm (with generator) | 4 hours | 5 minutes |
| NFPA 72 | Voice evacuation / MNS | 24 hours (4h w/gen) | 15 minutes |
| BS 5839-1 | Category M (Manual) or L (Life) | 24 hours | 30 minutes |
| BS 5839-1 | Category M/L with generator | 6 hours | 30 minutes |
| BS 5839-1 | Category P (Staffed / ARC monitored) | 24 hours | 30 minutes |
| BS 5839-1 | Category P (Unstaffed) | 24h + unoccupied period (max 72h) | 30 minutes |
For NFPA 72, the emergency generator must meet NFPA 110 requirements as a Type 10, Class 24, Level 1 installation, and the entire power path must qualify as Article 700 emergency power. If any part of the downstream distribution does not qualify, the full 24-hour battery standby is required regardless.
Standard Fire Alarm Battery Sizes
Fire alarm systems use 12V sealed lead-acid (SLA/VRLA) batteries. For 24V panels, two identical 12V batteries are connected in series. The table below lists standard capacities from the Yuasa NP series, the most widely used range in fire alarm applications.
| Capacity (Ah) | Typical Application | Approx. Dimensions (mm) | Approx. Weight |
|---|---|---|---|
| 1.2 | Very small single-zone panels | 97 x 48 x 55 | 0.6 kg |
| 3.2 | Small conventional panels | 134 x 67 x 64 | 1.3 kg |
| 7 | Small to medium conventional panels | 151 x 65 x 98 | 2.2 kg |
| 12 | Medium panels, multiple circuits | 151 x 98 x 98 | 4.1 kg |
| 17 | Larger conventional / medium addressable | 181 x 76 x 167 | 6.0 kg |
| 24 | Medium addressable systems | 166 x 175 x 125 | 8.3 kg |
| 38 | Large addressable systems / voice evacuation | 197 x 165 x 170 | 13.2 kg |
| 65 | Large networked systems | 350 x 166 x 174 | 21.5 kg |
| 100 | Very large / multi-panel networks | 407 x 173 x 210 | ~30 kg |
Always select the next standard size above your calculated minimum. A calculation result of 8.5 Ah means you need a 12 Ah battery, not a 7 Ah. Also confirm that your fire alarm panel supports the selected battery size – every panel has a maximum battery capacity determined by its charging circuit.
How Temperature Affects Battery Capacity
Battery capacity ratings assume a temperature of 25°C (77°F). In colder environments – plant rooms, external enclosures, unheated buildings – available capacity drops significantly. Neither standard’s formula explicitly accounts for temperature, so batteries in cold locations may need to be oversized beyond the formula result.
| Temperature | Available Capacity | Sizing Multiplier |
|---|---|---|
| 25°C (77°F) | 100% | 1.00 |
| 20°C (68°F) | ~96% | 1.04 |
| 10°C (50°F) | ~88% | 1.14 |
| 0°C (32°F) | ~77% | 1.30 |
| -10°C (14°F) | ~62% | 1.61 |
For example, if your formula gives 12.5 Ah and the batteries will sit in a location that drops to 0°C, multiply by 1.30 to get 16.25 Ah – meaning you need a 17 Ah battery rather than the 12 Ah that the basic calculation would suggest. High temperatures also matter: for every 8 to 10°C above 25°C, battery service life roughly halves.
Testing and Maintenance
NFPA 72 Testing Schedule
Semiannual: Measure individual battery voltage while on charger. Batteries reading below 13.26V should be replaced. Also verify charger output.
Every 3 years: Conduct a load test or use ohmic impedance testing to verify capacity. Batteries that cannot sustain the required load must be replaced.
Replacement: The 2022 edition requires batteries to be labeled with a replacement date not exceeding 4 years from installation (Section 10.6.10.1.3). Batteries must also be listed per UL 1989 or UL 2054 as of January 2024.
BS 5839-1 Testing Schedule
Weekly: User test of alarm system operation, which implicitly exercises the battery briefly.
Every 6 months: Professional service visit including battery checks. The 2025 edition allows a 5 to 7 month window between visits.
Replacement: Replace when capacity drops below 80% of rated value, when load tests fail, or per the manufacturer’s recommended date. The 2025 edition requires the replacement date to be marked directly on the battery.
Panel Charger Limits
Every fire alarm panel has a maximum battery capacity its charging circuit can support. Installing batteries larger than this limit means they may never fully recharge within the required timeframe (48 hours for NFPA 72, 24 hours for BS 5839-1). Always check the panel’s datasheet before selecting a battery size. If the calculated requirement exceeds the panel’s maximum, the system design needs to be reviewed – additional power supply units may be required.
What Changed in Recent Editions
NFPA 72 (2022)
The most impactful change for battery sizing was the increase of the aging correction factor from 1.20 (20%) to 1.25 (25%) under new Section 10.6.7.2.14. This means any calculation using the old 1.20 factor is non-compliant with the current code. Other changes include a requirement for batteries to be listed per UL 1989 or UL 2054 (effective January 2024) and a battery replacement label not exceeding 4 years from installation.
BS 5839-1:2025
Published in April 2025, this is a full revision replacing the 2017 edition. The battery formula was moved from Annex D to Annex E (normative) with clarified variable notation – but the calculation result is unchanged. Clause numbering throughout the standard has changed. The 2025 edition also introduced updated requirements for battery labeling and refined the service interval to a 5 to 7 month window rather than a fixed 6-month cycle.
Worked Examples
| Scenario | Standby | Alarm | Calculation | Battery |
|---|---|---|---|---|
| Small office, NFPA 72 | 250 mA | 750 mA | (0.25 x 24 + 0.75 x 0.083) x 1.25 = 7.58 Ah | 12 Ah |
| School with generator, NFPA 72 | 800 mA | 2.5 A | (0.8 x 4 + 2.5 x 0.083) x 1.25 = 4.26 Ah | 5 Ah |
| Retail store, BS 5839-1 | 350 mA | 1.5 A | 1.25 x (0.35 x 24 + 1.75 x 1.5 x 0.5) = 12.14 Ah | 12 Ah |
| Warehouse (Cat P, 48h unoccupied), BS 5839-1 | 300 mA | 1.0 A | 1.25 x (0.3 x 72 + 1.75 x 1.0 x 0.5) = 28.09 Ah | 33 Ah |
Tips for Accurate Load Calculations
The calculator is only as accurate as the current values you provide. Here is how to get them right:
- Standby current: Sum the quiescent draw of the panel itself, all detection devices on every loop, network interface cards, DACT/communicator modules, annunciator panels, and any powered field devices (beam detectors, aspirating systems). Panel datasheets list the base quiescent draw; device datasheets give per-device current.
- Alarm current: Calculate the worst-case scenario with all notification appliance circuits (NACs) active. For strobes, use the current for the actual candela setting configured – a 15cd strobe and a 110cd strobe on the same circuit have very different current demands. Add horn current for all horns, and speaker amplifier draw for voice systems.
- Networked systems: Each panel and remote power supply needs its own separate battery calculation. The network card’s standby current must be included in each panel’s load.
