Angle Iron Weight Calculator
Calculate the weight of angle iron based on dimensions and material.
Material
Profile Type
Dimensions
Length
Quantity
Price (Optional)
Results
What is Angle Iron?
Angle iron (also called angle steel or L-beam) is a structural steel or aluminum product with an L-shaped cross-section. Its two perpendicular legs create a 90-degree angle, providing exceptional strength and stability for a wide range of construction and fabrication applications.
Key Characteristics
- Profile Types: Equal (same leg widths) or unequal (different leg widths)
- Standard Materials: Mild steel, stainless steel, aluminum, brass, copper
- Typical Thicknesses: 3mm to 15mm (1/8″ to 5/8″)
- Standard Lengths: 6m (20ft) or 12m (40ft)
- Finish Types: Hot-rolled, cold-formed, galvanized, painted
Common Applications
- Construction: Framing, bracing, support structures
- Manufacturing: Equipment frames, reinforcement
- Transportation: Truck beds, trailers, shipping containers
- Infrastructure: Bridges, towers, utility structures
- DIY Projects: Shelving, furniture, brackets
Understanding Angle Iron Weight Calculation
Calculating the weight of angle iron is essential for material planning, cost estimation, load calculations, and transportation requirements. The weight depends on the cross-sectional dimensions, length, and material density.
Basic Weight Formula
- Area: Cross-sectional area in square units (cm², in²)
- Length: Total length of the angle iron
- Density: Material density (steel = 7.85 g/cm³)
Cross-Sectional Area Calculation
- a, b: Width of each leg
- t: Thickness of the angle iron
- t²: Subtracted to avoid counting the corner twice
For equal angles, both legs have the same width (a = b)
Material Density Reference
| Material | Density (g/cm³) | Density (lb/ft³) |
|---|---|---|
| Steel | 7.85 | 490 |
| Stainless Steel | 8.00 | 500 |
| Aluminum | 2.71 | 169 |
| Brass | 8.53 | 532 |
| Copper | 8.96 | 559 |
Working with Standard Angle Iron Sizes
Angle iron is typically manufactured in standard dimensions that vary by region and manufacturer. Using standard sizes can be more cost-effective and efficient than custom dimensions. Our calculator can help determine the closest standard size to your measurements.
Common Equal Angle Iron Sizes
| Leg Width (mm) | Thickness (mm) |
|---|---|
| 20 | 3 |
| 25 | 3, 5 |
| 30 | 3, 5 |
| 40 | 3, 4, 5, 6 |
| 50 | 3, 5, 6 |
| 60 | 5, 6, 8 |
| 75 | 6, 8, 10 |
| 90 | 6, 8, 10 |
| 100 | 8, 10, 12 |
| 150 | 10, 12, 15 |
Common Unequal Angle Iron Sizes
| Leg Width 1 (mm) | Leg Width 2 (mm) | Thickness (mm) |
|---|---|---|
| 40 | 20 | 3 |
| 45 | 30 | 3 |
| 50 | 30 | 5 |
| 60 | 30 | 5 |
| 60 | 40 | 5 |
| 65 | 50 | 5, 6 |
| 75 | 50 | 6 |
| 80 | 60 | 6, 8 |
| 90 | 60 | 6, 8 |
| 100 | 65 | 7, 8 |
| 100 | 75 | 8 |
| 120 | 80 | 8, 10 |
| 150 | 90 | 10, 12 |
| 200 | 100 | 10, 12 |
Practical Considerations When Using Angle Iron
Weight Tolerances
Actual angle iron weights can vary from theoretical calculations due to:
- Manufacturing tolerances in dimensions (typically ±2.5%)
- Variations in material density
- Surface treatments (galvanizing adds 3-7% to weight)
For critical applications, add a 5% margin to calculated weights.
Structural Calculations
When using angle iron for structural applications, consider:
- Load capacity depends on orientation and connection method
- Equal angles have symmetric properties
- Unequal angles have different strengths along each axis
- Position the larger leg where greater strength is needed
Cost Estimations
When estimating material costs:
- Prices typically quoted per weight unit ($/kg or $/lb)
- Smaller sizes often cost more per weight unit
- Specialty materials (stainless, brass) have significant premiums
- Allow for waste in cutting and fabrication (5-10%)
Transportation Requirements
For logistics planning:
- Standard lengths are optimized for shipping
- Consider weight limits for manual handling (≤25kg/55lb per person)
- Calculate total load for vehicle capacity
- Plan appropriate lifting equipment for heavy quantities
Common Standards and Specifications
Angle iron is manufactured according to various international standards that specify dimensions, tolerances, and mechanical properties:
ASTM A36/A36M
Standard specification for carbon structural steel with minimum yield strength of 36,000 psi (250 MPa). Most common standard for structural steel angles in North America.
EN 10056
European standard for structural steel equal and unequal leg angles, specifying dimensions, tolerances, and technical delivery requirements.
IS 808
Indian standard for dimensions of hot rolled steel beam, column, channel, and angle sections, commonly used throughout South Asia.
JIS G3192
Japanese standard for dimensions of hot rolled steel sections, including angle sections used in structural applications.
AS/NZS 3679.1
Australian/New Zealand standard for structural steel, including angle sections, with specific requirements for use in construction.
Frequently Asked Questions
Why do angle iron calculations subtract the thickness squared?
When calculating the cross-sectional area, thickness squared (t²) is subtracted to avoid counting the corner area twice. This occurs because both legs include the corner in their simple rectangular areas. The formula (a + b) × t – t² ensures accurate calculation.
How do I determine what size angle iron I need?
Determine the size based on your structural requirements, load-bearing needs, and application. For structural applications, consult engineering tables or a structural engineer. For non-critical applications, consider standard sizes that provide adequate strength while minimizing costs.
Which is stronger: equal or unequal angle iron?
Neither is inherently stronger—it depends on application and orientation. Equal angles provide balanced strength in both directions. Unequal angles offer greater strength along the axis of the longer leg, making them ideal when loads are predominantly in one direction.
How much extra weight does galvanizing add?
Hot-dip galvanizing typically adds 3-7% to the base weight of angle iron, depending on the thickness of the zinc coating and the surface area-to-weight ratio of the profile. Thinner angle sections gain proportionally more weight from galvanizing than thicker ones.
Can this calculator be used for metric and imperial units?
Yes, this calculator supports both metric units (mm, cm, m, kg) and imperial units (inches, feet, pounds) for all dimensions and weight calculations. You can freely mix input units and select your preferred output units.
How accurate are the weight calculations compared to actual product weights?
Theoretical calculations are typically accurate within ±2.5% of actual weights for standard mild steel products. Variations may occur due to manufacturing tolerances, material density differences, and surface treatments. For critical applications requiring precise weights, apply a safety factor.
MS Angle Weight Chart Pakistan (میلڈ اسٹیل اینگل ویٹ چارٹ)
Complete MS Angle weight chart for Pakistan market standards. All sizes follow Pakistan Standards (PS) and international specifications used in local construction and manufacturing.
| Size (mm × mm) | Thickness | Weight (kg/m) | Weight (kg/20ft) | Common Uses |
|---|---|---|---|---|
| 25 × 25 | 3mm | 1.12 | 6.82 | Light fabrication, small brackets |
| 38 × 38 | 3mm | 1.74 | 10.60 | Shop fixtures, small supports |
| 50 × 50 | 5mm | 3.77 | 22.96 | Construction bracing, frames |
| 75 × 75 | 6mm | 6.80 | 41.42 | Heavy construction, industrial |
Pakistan Market Information
- Standard Length: 20 feet per piece (market standard)
- Material Grade: MS Grade 40, Grade 50 available
- Manufacturing: Hot rolled as per PS-231
- Market Name: MS Angle, Mild Steel Angle, اینگل آئرن
Quality Standards
Pakistan manufactured MS Angles follow:
- Pakistan Standards (PS-231)
- ASTM A36 equivalent
- BS 4848 Part 4 equivalent
